Protocol Reference
The standards, ports, addresses and limits behind the eight protocols IoTServa reads, in one place. Public-standard facts only, with sources.
Specifications at a Glance
| Protocol | Standard | Medium | Topology | Range | Data Model |
|---|---|---|---|---|---|
| BACnet | ASHRAE 135 / ISO 16484-5 | IP networks (BACnet/IP over UDP, BACnet/SC over secure WebSocket) or RS-485 (MS/TP) | Peer to peer, routed between networks | Building and campus LAN | Objects with properties: Analog Input, Analog Value, Binary, Multi-state, Schedule, Trend Log |
| Modbus | Modbus Application Protocol (Modbus Organization) | RS-485 or RS-232 (RTU), Ethernet port 502 (TCP) | Client and server (master and slave) | Plant floor and switch room | Four tables: coils, discrete inputs, input registers, holding registers |
| KNX | ISO/IEC 14543-3, EN 50090 | Twisted pair (TP), KNX IP, KNX RF | Line and area bus, linked by couplers | A building or campus, with areas and lines linked over KNX IP | Group addresses (for example 1/2/5) carrying typed datapoints (DPT) |
| DALI | IEC 62386 (DALI Alliance, with DALI-2 and D4i certification) | Two-wire bus carrying power and data, read through a DALI gateway or controller | Bus, star or mixed wiring (loops not allowed), one bus power supply per line | Up to 300 m between the furthest devices on 1.5 mm2 cable, per DALI line | Control gear (drivers) and control devices (sensors, buttons), addressed by short address, group and scene |
| Serial Bus | TIA/EIA-485 and TIA/EIA-232 electrical layers, carrying protocols such as Modbus RTU and BACnet MS/TP | Serial cable: shielded twisted pair for RS-485, point-to-point for RS-232 | RS-485: multidrop daisy chain with termination at both ends. RS-232: one device per port | RS-485: about 1200 m at 100 kbit/s or lower, shorter at higher speeds. RS-232: about 15 m by the standard, longer at low baud rates on good cable | A master polls devices by address, one request at a time; the electrical layer carries the bytes, a protocol on top gives them meaning |
| MQTT | OASIS MQTT 3.1.1 (ISO/IEC 20922) and MQTT 5 | TCP and TLS (port 8883), WebSocket | Publish and subscribe through a broker | Anywhere with IP reachability | Topic strings with free-form payloads, optionally Sparkplug B |
| LoRa | LoRaWAN (LoRa Alliance) on LoRa modulation, AS923 plan in Malaysia | Sub-GHz radio to a gateway, then IP backhaul | Star of stars: devices, gateways, network server | Kilometres in open terrain, less indoors | Small uplink frames on a port, decoded by a payload decoder |
| BLE | Bluetooth Low Energy (Bluetooth SIG) | 2.4 GHz radio to a BLE gateway, then IP backhaul | Advertisers and scanners, or connected peripherals | Metres to tens of metres indoors (Bluetooth 5 Coded PHY reaches further in open line of sight) | Advertising data, or GATT services and characteristics |
Key Numbers and Where They Come From
| Protocol | Item | Value | Source |
|---|---|---|---|
| BACnet/IP | Default UDP port | 47808 (0xBAC0) | ASHRAE 135 |
| BACnet | Cross-subnet broadcasts | Need a BBMD, or a BACnet router between BACnet networks | ASHRAE 135 |
| Modbus TCP | Default TCP port | 502 | Modbus Organization |
| Modbus RTU | Device addresses | 1 to 247, one master per line | Modbus over Serial Line |
| Modbus RTU | Character frame | 11 bits: start, 8 data, even parity, stop (default) | Modbus over Serial Line |
| Modbus RTU | Frame separation | Silence of at least 3.5 character times | Modbus over Serial Line |
| RS-485 | Loads per line | 32 unit loads, up to 256 nodes with one-eighth unit load parts | Texas Instruments |
| RS-485 | Cable length | About 1200 m (4000 ft) at 100 kbit/s or lower | Texas Instruments |
| RS-485 | Termination | 120 ohm at each end of the trunk | Texas Instruments |
| RS-485 | Common-mode range | -7 V to +12 V | Texas Instruments |
| RS-232 | Typical limit | Point to point, about 15 m (2500 pF cable capacitance) | TIA/EIA-232, Modbus over Serial Line |
| DALI | Bus speed | 1200 bit/s | DALI Alliance |
| DALI | Devices per line | 64 control gear and 64 control devices | DALI Alliance |
| DALI | Control gear addresses | Short addresses 0 to 63, plus groups and scenes | DALI Alliance |
| DALI | Standard | IEC 62386, with DALI-2 and D4i certification programs | DALI Alliance |
| KNX | Group address | Written main/middle/sub such as 1/2/5, named in the ETS project | KNX Association |
| MQTT | Default ports | 1883 plain, 8883 over TLS | OASIS MQTT 3.1.1 |
| MQTT | QoS levels | 0 at most once, 1 at least once, 2 exactly once | OASIS MQTT 3.1.1 |
| LoRaWAN | Malaysia regional plan | AS923, listed as AS923-1 (confirm with the supplier) | LoRa Alliance |
| LoRaWAN | Device classes | Class A, B and C | LoRa Alliance |
| BLE | Band | 2.4 GHz, short range through gateways | Bluetooth SIG |
Limits are the standard's figures. Real installations are set by cable, devices and the manufacturer, so always check the device manual.
Serial Settings You Will Meet Most
| Baud Rate | Data Bits | Parity | Stop Bits | Where You See It |
|---|---|---|---|---|
| 9600 | 8 | Even | 1 | Modbus RTU default and the most common starting point |
| 19200 | 8 | Even | 1 | Common on meters and drives, and the highest speed that still uses 3.5 character times |
| 9600 | 8 | None | 2 | A frequent vendor variant, because no parity needs two stop bits for 11-bit frames |
| 38400 | 8 | None | 1 | Used by some newer meters and sensors, check the manual |
Both ends must match exactly. A wrong setting looks like a dead device.
